Beer tapping systems, beer coolers, dispensing systems and much more for tapping beer
A beer dispensing system, often also called a dispensing system or beverage dispensing system, is the prerequisite for filling beer from beer kegs, for example kegs, into drinking glasses. Good quality should always be ensured here, as several factors need to be taken into account for a perfect result:
- Temperature
- Carbon dioxide content
- Tap pressure
A professional dispensing system is standard in a restaurant, bar or pub. However, a high-quality beer dispensing system with the right accessories will also ensure a great atmosphere at any party at home. Tapping your own beer is not only fun, the result can also be convincing in terms of flavour and makes the barley juice from bottles and even from the popular can kegs look old. However, it is important to have a high-quality dispensing system, the right settings and a little practice. With the offers in our online shop, you can always be sure that you are only buying premium products in brewery quality at the best price. We are also available by telephone to provide you with advice and assistance - benefit from more than 25 years of experience in the field of beverage taps and accessories.
How does a beer dispensing system work?
Tapping systems or dispensing systems all work very similarly. The beer hose and the pressurised gas line, which is connected to a CO2 cylinder, are connected to the beer keg via the keg cap (or dispensing head). A pressure reducer allows the carbon dioxide (CO2) to flow into the beer keg so that both the carbon dioxide is formed in the beer and the beer is forced through the beer hose via a riser pipe at the outlet of the tap head. In this way, the beverage reaches the actual dispensing system, where it is usually cooled wet by a dry beer cooler or beer cooler and can be tapped at the beer or tap. Incidentally, a 2 kg bottle ofCO2 is sufficient for around 500 litres of freshly tapped beer.
Everything for beer dispensing from a single source
As a long-standing supplier of beverage taps and accessories, we offer everything "from keg to glass" in our online shop. In addition to tapping systems, tap heads and beer coolers, we also offer everything you need for cleaning beverage tapping systems. Compare our prices in what is probably the largest online shop for beverage dispensing systems and accessories. We always try to offer you the best price on the Internet. If you find the same item cheaper on the Internet, please contact us.
Convert Quooker Cube to Co2 cylinder complete set Optimise your QUOOKER CUBE with our premium pressure regulator for the use of reusable CO2 cylinders (500 g, 2 kg, 6 kg or 10 kg - without riser tube!) Converting your Quooker CUBE system offers you long-term savings on CO2 filling costs and frees you from the manufacturer's own CO2 cylinders. You also have the option of returning to the original state at any time. Retrofitting is straightforward and requires no special technical knowledge. You can do this yourself by simply changing a hose connection. It is also possible to relocate the CO2 supply cylinder to other premises such as a plant room or cellar. Our premium pressure regulator, with a working pressure capacity of 7 bar and an inlet connection, can be connected to all commercially available reusable CO2 cylinders (500 g, 2 kg, 6 kg, 10 kg) WITHOUT a riser pipe (W 21.8 x 1/14"). Installation is carried out using the Co2 spanner included in the set. Our pressure regulator is compatible with all QUOOKER devices that use the QUOOKER CUBE element, including the QUOOKER CUBE (1st generation) and the QUOOKER CUBE "Next Generation" (2nd generation / from the end of 2021). The conversion is simple, as only one hose needs to be reconnected thanks to the push-in connector from John Guest. For the QUOOKER CUBE (2nd generation / from the end of 2021), you need an optional CO2 pressure hose to convert your CUBE reversibly. Our pressure regulator has a compact design that is perfect for confined spaces in the base cabinet. With two pressure gauges for working and cylinder pressure, you have full control over the respective values. By adjusting the working pressure in the range from 0 to approx. 4 bar, you can set the bubble strength according to your individual preferences. The pressure should not exceed 4 bar and our conversion kit contains a pre-assembled 3 metre long carbonic acid hose measuring 8x4 mm for seamless connection to your Quooker Cube. This hose is ready for immediate use and makes installation much easier. The connection to the pressure reducer is made effortlessly using a 1/2 inch wing nut, while a practical 6mm/8mm 90 degree angle plug-in connector is used on the Quooker. In addition to the hose, the scope of delivery also includes a carbon dioxide bottle holder with chain for bottles with a diameter of 120 - 210 mm. A spanner for the pressure reducing valve is also included to make handling and maintenance even easier Scope of delivery set in construction & catering quality: CO2 pressure regulator Pressure regulator 7 bar with working and content pressure gauge suitable for cylinder connection W 21.8 x 1 1/4 inch Spanner for pressure reducing valve 30mm & 32mm Wall bracket for carbon dioxide bottle (Co2 bottle) for screwing on with chain for 1 bottle 120mm - 210mm 3 metre CO2 hose ready assembled with 1/2 inch wing nut, straight stainless steel grommet, seal and 6mm/8mm 90 degree angle plug-in connector
Cooler circuit carbonator ICE CORE 1 2 drinks per minute Dispensing capacity: 84 drinks á 340 ml Water tank: 10 litres Ice bank: 4 kg Cooling coil still: 1 Cooling coil syrup: 4 max. python length: 12 m Refrigerant: R290 Connections: RG 5/16" + 3/8" Housing material: galvanised Dimensions W/D/H: 625/401/285 mm Weight: 30.5 kg
Cooler circuit carbonator ICE CORE ECO 2 drinks per minute Refrigerant: R290 Housing material: galvanised Dispensing capacity 751 drinks A 340 ml Ice bank 26 kg Water bath 65 litres Cooling coil still 1 Cooling coil syrup 8 Premix cooling coil 2 max. python length 40m Dimensions in mm W/D/H 982/590/678 Weight in kg 94 Connections 1/2" BSF + 5/8" UNF
Cooler circuit carbonator ICE CORE ECO 2 drinks per minute Refrigerant: R290 Housing material: galvanised Dispensing capacity 181 drinks A 340 ml Ice bank 7 kg Water bath 25 litres Cooling coil still 1 Cooling coil syrup 6 Premix cooling coil - max. python length 30m Dimensions in mm W/D/H 762/440/530 Weight in kg 63 Connections JG 5/16" + 3/8"
Cooler circuit carbonator ICE CORE ECO 2 drinks per minute Refrigerant: R290 Housing material: galvanised Dispensing capacity 459 drinks A 340 ml Ice bank 15 kg Water bath 43 litres Cooling coil still 1 Cooling coil syrup 8 Premix cooling coil 2 max. python length 40m Dimensions in mm W/D/H 870/526/648 Weight in kg 77 Connections 1/2" BSF + 5/8" UNF
Cooler circuit carbonator ICE CORE ECO plus 2 drinks per minute incl. connection kit Refrigerant: R290 electrical still water control Connection consisting of: Water inlet: nozzle + nut for 3/8" hose ID CO2 inlet: nozzle + nut for 1/4" hose ID Flow and return: nozzle + nut for 1/2" + 3/8" hose ID Syrup: Spout + nut for 3/8" hose ID Still water: Spout + nut for 3/8" hose ID Dispensing capacity 181 Drinks A 340 ml Ice bank 7 kg Water bath 25 litres Cooling coil still 1 Cooling coil syrup 6 Premix cooling coil - max. python length 30m Dimensions in mm W/D/H 762/440/530 Weight in kg 63 Speed-controlled recirculation - galvanised housing Galvanised housing
Cooler circuit carbonator ICE CORE ECO plus 2 drinks per minute incl. connection kit Refrigerant: R290 electrical still water control Connection consisting of: Water inlet: nozzle + nut for 3/8" hose ID CO2 inlet: nozzle + nut for 1/4" hose ID Flow and return: nozzle + nut for 1/2" + 3/8" hose ID Syrup: Spout + nut for 3/8" hose ID Still water: Spout + nut for 3/8" hose ID Dispensing capacity 459 Drinks A 340 ml Ice bank 15 kg Water bath 43 litres Cooling coil still 1 Cooling coil syrup 8 Premix cooling coil 2 max. python length 40m Dimensions in mm W/D/H 870/526/648 Weight in kg 77 Speed-controlled recirculation x Stainless steel housing
Cooler circuit carbonator ICE CORE ECO plus 2 drinks per minute incl. connection kit Refrigerant: R290 electrical still water control Connection consisting of: Water inlet: nozzle + nut for 3/8" hose ID CO2 inlet: nozzle + nut for 1/4" hose ID Flow and return: nozzle + nut for 1/2" + 3/8" hose ID Syrup: Spout + nut for 3/8" hose ID Still water: Spout + nut for 3/8" hose ID Dispensing capacity 751 Dr. A 340 ml Ice bank 26 kg Water bath 65 litres Cooling coil still 1 Cooling coil syrup 8 Premix cooling coil 2 max. python length 50m Dimensions in mm 982/590/678 Weight in kg 94 Speed-controlled recirculation x Stainless steel housing
Cooling and stilling coil for beer made of CNS Cooling and stabilising coil made of CNS NW 7 mm, complete with wall mounting. Dimensions: 10/10 cm square, 7 m long Pressure reduction approx. 0.1 bar/m coil=0.7 bar
Cover plates CNS 1 cm bevelled, for covering column holes. Cover shelf 220 x 220 mm without hole, Cover shelf 220 x 220 mm 45 mm hole, 60 mm hole, 90 mm hole, Cover shelf 280 x 280 mm 45 mm hole, 90 mm hole,
Cover plates for catering sinks CNS perforated, with locking pins. For bowls: 500 x 300 mm, 400 x 400 mm,
Crate dispensing column stainless steel Stainless steel dispensing column for 1 or 2 taps. The height in the centre of the tap is 400 mm. Dispensing column WITHOUT TAPS Dimensions: W/D/H 1-pipe, 140(95)/100/480 mm 2-pipe, 155(110)/120/480 mm Please order taps in the taps section!
Crimp ring for CNS pipe 8 x 0.5 mm ATTENTION: STAFF PRICES NOTE!!! (see below)
CT 30 sparkling and table water dispenser Cool sparkling & table water from the water pipe Table water dispenser UTK CT 30, under-counter version Dispensing capacity: 38 l/h, 2-pipe, 1/5 HP, 230 V, 50 Hz, 395 W, 1.8 A Pipe diameter 5 mm. Under-counter appliance for connection to dispensing column. The entire technology is integrated in the appliance,. All you need is a CO2 cylinder, pressure reducer 7 bar and CO2 hose (filter system optional). Individually adjustable dispensing temperature. For catering, offices, hotels, doctors, etc. 1 line for sparkling water 1 line for still water Water inlet 3/8" Beverage outlets 1/2" BSF Dimensions: W/D/H 413/285/456 mm Weight: 30 kg Ready to dispense in 10 minutes
Sparkling and table water dispenser CT 60- undercounter Cool sparkling & table water from the water pipe Table water unit UTK CT 60, under-counter version The under-counter cooling units for table water (dry carbonators) are used in combination with a dispensing column. They are suitable for installation in existing counters or cabinets. The system is easy to install, simple to operate and easy to clean. All components that come into contact with water are made of high-quality stainless steel. With refrigerant R290environmentally friendly and energy efficient Water types: chilled sparkling water + chilled table water Electrical connection values: 230 V / 50 Hz / 3.4 A / 540 WPipes: 2 (5 i.D.)Ready to dispense in: 5 minutesDispensing capacity: 58 l/h at Δt 10KW/D/H: 413/285/456 mmWeight: 28 kg Compressor volume 62 dB: Quieter than most fully automatic coffee machines: At full compressor output (ambient temperature 32°C, relative humidity 65%), the volume corresponds to a normal conversation (approx. 60 dB). In standby mode, the appliances are virtually silent.
Date stickers 2018 For acceptance and recurring testing, marking, etc., consisting of Base badge 105 x 57 mm, sheet with 10 pieces Inspection badges 35 mm Ø, 12 months, PU 10 pieces Year 2018 Price per PU,
Decentralised connection box for LogiCO2 gas detection system The decentralised connection box for the LogiCO2 gas detection system offers you a reliable CO2 safety system solution for various areas of application. With this innovative box, a remote connection to fire brigades via the existing fire alarm system becomes standard. Whether as part of your safety system in residential buildings, offices or commercial premises, this connection box guarantees effective monitoring and early warning of CO2 leaks. It protects people and the environment from dangerous concentrations of this gas. In addition to its main function as a CO2 safety system, the decentralised connection box can also be used for external ventilation.
Diaphragm pump Blusoda 30 and 45, Box 30 and 60
Dispensing column Beer dispenser Double dispensing column 4 - 8 ltg. Here we offer you our popular double beer dispenser. With this dispenser you can install up to 8 taps (max. 4 taps per side) The beer dispenser can be ordered in various surface designs. Of course, this dispensing column is also used in the catering trade. The beer dispensing column is attached to the beer counter or beer bar using 4 x threaded rods Beer bar or beer counter counter. The fixing material is included in the scope of delivery. Technical specifications: Material: Stainless steel, with inspection flap for tap mounting Height: 454 mm, to centre of tap 400 mm Diameter of standpipe 108 mm 4 ltg. Width 2 x 450 mm 6 ltg. Width 2 x 560 mm 8 ltg. Width 2 x 670 mm Design: Matt brushed stainless steel Polished stainless steel Polished stainless steel TIN-gold coloured (SCRATCH RESISTANT GOLD OPTICS) Scope of delivery: Bar columns 4 x M8 threaded rods for fastening The dispensing column is supplied WITHOUT taps, please order these in the section Dispensing taps !
Dispensing column beer dispenser gooseneck Beer dispenser fashion swan neck Chrome or brass finish, WITHOUT TAPS Height 450 mm, height with beer tap centre 415 mm, base 142 mm Ø. Available versions: Chrome-plated brass 1-pipe Chrome-plated brass 2-pipe* Polished brass 1-pipe Polished brass 2-pipe* *Attention! Only suitable for 7 mm hose line! ATTENTION: For hose assembly, also order a socket: for 7 mm order no. T26, for 10 mm order no. T27 For taps with 35 mm spigots, order a spacer sleeve: Spacer sleeve 20 mm chrome order no. T10A, spacer sleeve, 20 mm brass order no. T12A Please order taps in the Taps section!
Dispensing column Beer dispenser model Adria Dispensing column model "Adria" incl. beverage line 6.7/9.5 5/8" thread for hand-turned tapHeight 504 mm, height centre of tap 430 mm, base 70 mm Ø. Design: Completely made of chrome, running to the right, from the bartender's point of view 1-pipe Completely made of chrome, running to the left, 1 pipe from the bartender's perspective Completely made of chrome, running to the centre, from the bartender's point of view, 1-line The dispensing column is supplied WITHOUT taps, please order these in the section Taps !
Dispensing column Beer dispenser model Bistro Dispensing column model "Bistro" incl. beverage line 6.7/9.5 mm 5/8" thread for tapHeight 480 mm, height centre of tap 350 mm, base: width 105 mm depth 130 mm Finish: chrome matt wood with chalkboard 1-line The dispensing column is supplied WITHOUT taps, please order these in the section Taps !
Dispensing column Beer dispenser Model Bolt Dispensing column model "Bolt" incl. beverage line and accompanying cooling 6.7/9.5 mm 5/8" thread for hand-turned tapHeight 415 mm, height centre of tap 350 mm, base 110 mm Ø. Design:Completely made of chrome 1-pipe The dispensing column is supplied WITHOUT taps, please order these in the section Taps !
Dispensing column Beer dispenser Model Break Dispensing column model "Break" incl. beverage line and accompanying cooling 6.7/9.5 mm 5/8" thread for hand-turned tapHeight 410 mm, height centre of tap 380 mm, base 90 mm Ø. Design: Completely made of chrome 1-pipe Completely made of chrome 2-pipe The dispensing column is supplied WITHOUT taps, please order these in the section Taps !
