Beer cooler tapping systems Cooling unit repair
Simply repair a beer dispenser, beer cooler or accompanying cooler
In most cases, it is only small things that are faulty in a beer cooler, accompanying cooler, dispensing system or bar, but these can have major consequences. They are often small parts such as a propeller on a blast chiller, the door seal on your bar counter or a thermostat on your refrigeration system. These things are usually easy to repair yourself.
Original spare parts and tools for repairing your beer cooler
And if you want to repair your beer cooling system, we also offer a wide range of suitable items. Buy the right top-quality spare parts for repairing your beer dispensing system from us too! Our competent customer service team will be happy to answer any questions you may have.
Ritchie Ratchet spanner Ratchet spanner Heavy duty 1/4“ (6.5 mm), 5/16“ (8 mm), 3/16“ (5 mm), 3/8“ (9.5 mm)
RTU Advanced Condenser Cleaner Removes common dirt and deposits Increases the performance of the system Also suitable for condensers inside buildings 1 litre pump bottle You can find more RTU Advanced products HERE: Use biocidal products with care. Always read the label and product information before use.
RTU Advanced Condenser Cleaner Removes common dirt and deposits Increases the performance of the system Also suitable for condensers inside buildings 5 litre canister Use biocidal products with care. Always read the label and product information before use.
Contents: 5 Liter (£21.29 / 1 Liter)
RTU Advanced evaporator cleaner RTU Advanced Vaporiser Cleaner and disinfectant With QX-60® - Kills 99.9% of all bacteria and fungi within 60 seconds Removes dirt, sludge and mould Improves indoor air quality Meets European standards for: Bactericides and fungicides EN1040, EN1275,EN 1276 and EN 1650 5 litre canister Use biocidal products with care. Always read the label and product information before use.
Contents: 5 Liter (£21.65 / 1 Liter)
RTU Advanced vaporiser cleaner and disinfectant With QX-60® - Kills 99.9% of all bacteria and fungi within 60 seconds Removes dirt, sludge and mould Improves indoor air quality Complies with European standards for bactericides and fungicides EN1040, EN1275, EN 1276 and EN 1650 1 litre pump bottle You can find more products from RTU Advanced HERE Use biocidal products with care. Always read the label and product information before use.
Saber AG04 agitator motor Agitator motor for beer cooler, Saber type AG-4 complete with paddle Shaft length: 150 mm Motor dimensions: 67 x 94 x 71 mm (H/W/D) 230V, 50Hz, 22 W, 2,700 rpm ATTENTION: ONLY SUCCESSOR MODEL NAG20-ATEX AVAILABLE!!!!!
Saber MID7 agitator motor with pump, beer accompanying cooling pump The MID 7 beer accompanying cooling pump is easy to replace and suitable for almost all python coolers or beer accompanying coolers. You can find the technical data for the pump with agitator motor for your dispensing system in our download area. The pumps we offer ensure constant cooling of your beer line during the beer accompanying cooling process. Accompanying beer cooling pump including internal start-up condenser. Pump for accompanying cooler or pump for python cooler. (SH=head, LW=pipe path, WL=shaft length, GH=total height) SAMEC 6 (MID7) SH=6 m, LW=20 m, WL=195 mm, GH=284 mm
Saber Samec Agitator Motor with Pump, Beer Accompaniment Cooling Pump The beer accompanying cooling pump is easy to exchange and suitable for almost all python coolers or beer accompanying coolers. The technical data of the pump with agitator motor for your beer tapping plant can be found in our download area. Our offered pumps provide a constant cooling of your beer line at the beer accompanying cooling. Beer accompanying cooling pump including internal starting condenser. Pump for beer tracing cooler or pump for python cooler. (SH = head, LW= line path, WL = wavelength, GH= total head) SAMEC 6 (MID7) SH = 6 m, LW = 20 m, WL = 195 mm, GH = 284 mm, SAMEC 12(STB) SH = 12 m, LW = 20 m, WL = 220 mm, GH = 327 mm, SAMEC 18 (STC) SH = 18 m, LW = 30 m, WL = 235 mm, GH = 358 mm,
Saber Samec agitator motor with pump, beer accompanying cooling pump The SAMEC 18 beer accompanying cooling pump is easy to replace and suitable for almost all python coolers or beer accompanying coolers. You can find the technical data of the pump with agitator motor for your dispensing system in our download area. The pumps we offer ensure constant cooling of your beer line during the beer accompanying cooling process. Accompanying beer cooling pump including internal start-up condenser. Pump for accompanying cooler or pump for python cooler. (SH=head, LW=pipe path, WL=shaft length, GH=total height) SAMEC 18 (STC) SH=18 m, LW=30 m, WL=235 mm, GH=358 mm,
Saber Samec agitator motor with pump, beer accompanying cooling pump The SAMEC 12 beer accompanying cooling pump is easy to replace and suitable for almost all python coolers or beer accompanying coolers. You can find the technical data of the pump with agitator motor for your dispensing system in our download area. The pumps we offer ensure constant cooling of your beer line during the beer accompanying cooling process. Accompanying beer cooling pump including internal start-up condenser. Pump for accompanying cooler or pump for python cooler. (SH=head, LW=pipe run, WL=shaft length, GH=total height) SAMEC 12(STB) SH=12 m, LW=20 m, WL=220 mm, GH=327 mm,
Schrader valve piercing valve Schrader attachment valve for pressure measurement/filling of refrigeration/air conditioning systems complete with Schrader valve and cap, suitable for tubes 6 mm, 8 mm and 10 mm. for pressure measurement/filling of refrigeration/air conditioning systems complete with Schrader valve and cap, suitable for tubes 6 mm, 8 mm and 10 mm.
Schrader valve complete cap with integrated spanner, 7/16“ thread, solder connection, incl. valve. Schrader valve with 6 mm copper tube Schrader valve
Screwdriver with ratchet function Screwdriver with attachments for all common valve cores (large sizes) • Externally compact, yet very robust • 7 tools in one • Wide, short handle to ensure maximum power transmission even where space is limited • Can be used with ratchet function (left/right) or without ratchet function • 7 bit inserts are firmly stored in the transparent handle • Slot 5.0 and 6.0 • Cross (Philips) 1 and 2 • Valve core inserts 4.4 and 5 • As well as a tap for valve core inserts to be able to recut the thread on service valves
Seals Drum KC GRK KRT Frigo Large-volume, easy-to-change hollow chamber plug-in seals made of PVC. Colour: RAL7001 silver-grey Order number External panel dimensions Price Drum cooler new Height 1110 mm from 01-2005 E45-301-010 Gasket T2/4FASS-H1110 550 x 1.040 E45-301-012 Gasket T6FASS-H1110 750 x 1.040 E45-301-013 Gasket T8/10FASS-H1110 910 x 1.040 Drum cooler old until 12-2004 E45-301-000 Gasket T2/4FASS 550 x 940 E45-301-002 Gasket T6FASS 750 x 940 E45-301-003 Gasket T8/10FASS 910 x 940
Self-adhesive insulating tape black, 10 m roll. Flexible, closed-cell foam based on synthetic rubber. Fire protection class B2. Back with grid and pressure-sensitive adhesive coating. -45°C to +105°C. • Roll size: 10 m x 50 mm x 3 mm. • Colour: black
Contents: 10 Laufende(r) Meter (£0.83 / 1 Laufende(r) Meter)
Self-adhesive insulating tape black self-adhesive insulating tape black 10 m roll. Flexible, closed-cell foam based on synthetic rubber. Technical data: Fire protection class B2. Back with grid and pressure-sensitive adhesive coating -45°C to +105°C Roll size: 10 m x 50 mm x 3 mm Colour: black
Service Mirror For all poorly visible areas • With these mirrors, it is possible to quickly and accurately view concealed areas. You can see a viewing angle of 360°. A mixture of • spring steel allows constant use in all areas. • The mirrors are freely movable and can be held in any position . 175 mm extendable up to 490 mm, diam. 32 mm. Price per piece, order no. SP1 Round Telescopic pocket mirror 52 mm diameter. Complete length 290 mm Extendable up to 455 mm. Price per piece, order no. SP2 Oval Pocket mirror 25 mm x 50 mm. Length 205 mm extendable up to 510 mm Price per piece, order no. SP5 Please select the appropriate version from the menu!
Dispensing valve pliers Piercing pliers with Schrader valve • Dispensing valve 3/16“ (5 mm) to 7/8“ (22 mm) • For removal of refrigerant samples or for entire filling and emptying processes.
Thermostat beer cooler, python cooler water bath cooler Ranco The RANCO thermostat ice K50H1121007 This Ranco thermostat is used in beer coolers such as the Python cooler or also Water bath cooler. The temperature can be regulated up to + 12 degrees Celsius. Ice up to +12°C for water bath machines Ranco item no.: K50H1121007
Thermostat Danfoss KP61 WITH stop auto switch Ambient temperature: 40 - +65°C (+80 °C for max. 2 hours). Switch: single-pole, changeover switch (SPDT. Contact load, AC: AC1: 16 A, 400 VAC3: 16 A, 400 VAC15: 10 A, 400 VMaximum starting current (L.R.): 112 A, 400 VContact load, DC: DC13: 12 W, 220 V control currentCable connection: A Pg 13.5 cable gland can be used for cables with a diameter of 6 - 14 mm. For cables with 8-16 mm, a Pg 16 cable gland can be used.Protection class: IP 30 according to IEC 529 if the unit is mounted on a flat surface or with a mounting bracket with all unused holes covered. Type code KP61 Unit weight 0.370 [kg] Ambient temp. -40 - 65 °C Ambient temp. -40 - 150 °F Approval BV, c UL us UL873, CS C22.2, CCC, CE, DNV, EAC, GL, LR, LVD, PZH, RINA, RMRS, RoHS China Cap. tube length 78 3/4 in Cap. tube 2.000 mm Filling type Vapour Contact function SPDT Contact class AC1=16 A, 400 V Contact class AC15=10 A, 400 V Contact class AC3=16 A, 400 V Contact class DC13=12 W, 220 V Contact class LR=112 A, 400 V Diff./max. range 1,5 - 7,0 K Diff. Max. Range setting 1,5 - 7,0 °C Diff./min. Range 5,5 - 23,0 K Diff. Min. range setting 5,5 - 23,0 °C Difference type adjustable EAN 5702428010955 Electrical connection - additional information Rubber cable glands Electr. connection size 6-14 mm Electrical specification Standard EN 60947-5 IP30 1 Further information With µ stop Glow lamp No Max. Sensor temp. 120 °C Max. Sensor temp. 248,0 °F Pack size Multi pack Pack description Temperature control Product group Switches and thermostats Prod. name Thermostat Quantity/Pack 32 pc Reset Auto reset Sensor size (Ø x L) 3/8 x 2 3/4 in Sensor size 9.5 x 70 mm Sensor Remote sensor Temp. range -30 - 15 °C Temp. range -22 - 59 °F UL approval E31024
Thermostat Danfoss KP62 WITH stop/auto switch and protective cover Danfoss no. 060L111066 Range: -30°C ... 15°C Differential: 5 ... 20 K / 2 ...8 K Sensor: Room sensor
Thermostat TR711 with remote sensor One-way thermostat with nickel-plated sensor. The thermostats are designed with a changeover contact with fixed set differential. Temperature range: -35°C to +35°C Capillary tube: 1.5 m Switch: 1 changeover contact Switching capacity: 16(4) A, 230 V AC Switching differential: 2 K (fixed) Electrical connection: blade terminal Protection class: -
Universal refrigeration controller for deep-freezing Universal refrigeration controller for deep-freezing type DR2 Front panel installation, 230 V supply voltage PTC/NTC sensor compatible, therefore ideal for service/customer service as no complex sensor replacement necessary Dimensions: W/D/H 60/77/35 mm Cut-out: W/H 71/29 mm Thermostat sensor: 2 x NTC Measuring range: -45°C to + 66°C. 1 relay output compressor 16 A, 1 relay output evaporator fan, 1 relay output heating
